SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001]

  • SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001]
  • SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001]
Place of Origin Shanghai
Brand Name KSTONE
Certification ISO9001
Model Number KS2001
Document gas tester.pdf
Minimum Order Quantity 1
Price $5000-$6000
Packaging Details Carton / Wooden Box
Delivery Time 30waok days
Payment Terms T/T
Supply Ability 10 set/year
Product Details
Accuracy Level 0.2 Level Pressure Display Resolution 0.0001 MPa
Pressure Calibration Range 0 ~ 1.0 MPa Contact Resistance Range 0 ~ 25 Ω
Resistance Measurement Accuracy ±5%FS Resistance Display Resolution 1 MΩ
Temperature Measurement Range -50°C ~ 150°C Weight 2.5 Kg
Highlight

SF6 Density relay check

,

SF6 Density meter check

,

0.2 level SF6 Density relay check
Leave a Message
Product Description
SF6 Density Relay Calibration, SF6 Pressure Gauge, Fully Automatic Calibration, KS2001

SF6 switch is a high-voltage appliance widely used in power system, and the reliable operation of SF6 switch has become one of the most concerned issues in the power supply department. SF6 gas density relay is an important component used to monitor SF6 gas density change in SF6 switch body during operation, its performance directly affects the safety of SF6 switch operation. SF6 gas density relay running in the field because of infrequent action, after a period of time often appear inflexibility, poor contact contact and other phenomena, and some will appear density relay temperature compensation performance deteriorates, when the ambient temperature sudden change often lead to SF6 density relay misoperation. Therefore, DL/T596 "Preventive Test Procedures for Power Equipment" stipulates that each SF6 switch user should regularly verify SF6 gas density relays. From the actual operation situation, the SF6 density relay and pressure gauge in the field operation are also very necessary for regular calibration

Technical Specifications Table
Parameter Specification
Power Supply Lithium battery or AC220V/50Hz
Power Consumption 4W
Accuracy Level 0.2 level
Pressure Display Resolution 0.0001 MPa
Pressure Calibration Range 0 ~ 1.0 MPa
Contact Resistance Range 0 ~ 25 Ω
Resistance Measurement Accuracy ±5%FS
Resistance Display Resolution 1 mΩ
Temperature Measurement Range -50°C ~ 150°C
Temperature Measurement Accuracy ±0.5°C
Temperature Display Resolution 0.1°C
Verification Object Single alarm/block/overpressure, any combination of alarm + block + overpressure
Pressure Type Absolute pressure, relative pressure
Display 800×600 graphic color LCD screen
Operation Mode Resistive touch screen
Printer High-speed thermal micro printer
Printing Format Chinese character report type printing
Storage Capacity Up to 150 test results
Dimensions Main unit: 380mm×320mm×180mm
Accessory box: 465mm×370mm×145mm
SF6 Gas Density Display Pressure at measured environment, equivalent pressure at 20°C
Weight 2.5 kg

SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001] 0

SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001] 1

SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001] 2

SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001] 3

SF6 Density Relay Chec SF6 Density Meter Check 0.2 Level [KS2001] 4

packing list

1 host

1 power cord

1 high-pressure steel cylinder

One intake pipe (250cm)

Measure 1 trachea (250cm)

One vent pipe (80cm)

Transition joint (serial numbers ○ 1- ○ 14) 1 set

Inflatable adapter (serial number ○ 15) 1 piece

Public connector (serial number ○ 16) 1 piece

16-core test wire

2 rolls of printing paper

2 rolls of raw material tape

2 2A insurance tubes

1 manual
