Integrated Online Monitoring System SF6 Gas Density Monitor Temp Humidity Meter Self Calibration [KS-201]

Large Image : Integrated Online Monitoring System SF6 Gas Density Monitor Temp Humidity Meter Self Calibration [KS-201]

Product Details:

Place of Origin:	Shanghai
Brand Name:	KSTONE
Certification:	ISO9000
Model Number:	KS-201

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	$2000-$100000
Packaging Details:	Carton / Wooden Box
Delivery Time:	7-10 work days
Payment Terms:	T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Measurement Parameters:	Temperature, Humidity, Dew Point	Dew Point Range:	-80°C To +20°C (customizable)
Temperature Accuracy:	±0.5°C	Humidity Accuracy:	±2% RH (20–90% RH Range)
Dew Point Accuracy:	±1°C (-60–20°C); ±2°C (-80–60°C)	Response Time:	≤10s (90% Response, 25°C, 60% RH)
Highlight:	Integrated Online Monitoring System , Self Calibration Online Monitoring System , Self Calibration sf6 gas density monitor

KS-201 Online Dew Point & Temp Humidity Meter | Imported Sensors, Touch Screen, Self-Calibration

Brief Introduction

The KS-201 online temperature and humidity meter employs high-performance imported sensors to ensure accurate and stable measurement results. The integrated instrument cluster supports real-time monitoring, file management, time scheduling, parameter configuration, and other functions, featuring a touch-screen interface for intuitive human-computer interaction. It is widely applied in new energy, air compressors, petrochemicals, natural gas, industrial gases, semiconductors, drying processes, food production, power systems, machinery manufacturing, air separation, and pharmaceuticals—suitable for online analysis in gas environments with strict control requirements. The device supports standalone installation or multi-sensor configuration with a central display host; contact us for customization details.

Product Features

LED Color Touch Screen:Intuitive operation with multi-parameter synchronous display.
Sensor Self-Diagnosis:Automatic fault detection for maintenance efficiency.
Open Self-Calibration:User-configurable calibration for measurement accuracy.
Dynamic Curve Tracking:Real-time trend visualization of measurement processes.
Fast Response System:Swift data acquisition with simple operation logic.
Dew Point Pressure Conversion:Automatic adjustment from pressure dew point to atmospheric pressure.
Large-Capacity Storage:Automatic data logging with USB export capability.

Technical Parameters

Parameter	Details
Measurement Parameters	Temperature, humidity, dew point
Dew Point Range	-80°C to +20°C (customizable)
Temperature Accuracy	±0.5°C
Humidity Accuracy	±2% RH (20–90% RH range)
Dew Point Accuracy	±1°C (-60–20°C); ±2°C (-80–60°C)
Response Time	≤10s (90% response, 25°C, 60% RH)
Display	7-inch LED color touch screen (800×480 pixels)
Communication	USB, RS485 (Modbus protocol)
Power Supply	AC 220V±10% / DC 24V (optional)
Operating Temperature	-20°C to +50°C
Storage Temperature	-40°C to +70°C
Dimensions	190×144×100 mm (panel mount)
Installation	Panel-mounted / wall-mounted (optional accessories)
