OEM Touchscreen SF6 Monitor Sensors Gas Density Meter Device [KS-201]

  • OEM Touchscreen SF6 Monitor Sensors Gas Density Meter Device [KS-201]
Place of Origin Shanghai
Brand Name KSTONE
Certification ISO9000
Model Number KS-201
Minimum Order Quantity 5
Price $2000-$100000
Packaging Details Carton / Wooden Box
Delivery Time 7-10 work days
Payment Terms T/T
Supply Ability 1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Measurement Parameters Temperature, Humidity, Dew Point Dew Point Range (customizable) -80°C To +20°C
Display 7-inch LED Color Touch Screen (800×480 Pixels) Communication USB, RS485 (Modbus Protocol)
Power Supply AC 220V±10% / DC 24V (optional) Temperature Accuracy ±0.5°C
Humidity Accuracy ±2% RH (20–90% RH Range) Operating Temperature -20°C To +50°C
Highlight

Touchscreen sf6 monitor

,

OEM sf6 monitor

,

OEM sf6 gas density meter
Leave a Message
Product Description
KS-201 Online Dew Point & Temperature Humidity Meter | Imported Sensors, Touch Screen Calibration

Brief Introduction

The KS-201 online dew point and humidity meter utilizes high-precision imported sensors to deliver accurate, stable measurements. Its integrated system enables real-time monitoring, data management, time scheduling, and parameter configuration, featuring a touch-screen interface for intuitive operation. Ideal for new energy, petrochemicals, semiconductors, power grids, and pharmaceutical industries, it suits online gas environment analysis with strict control requirements. The device supports standalone use or multi-sensor setups with a central host—contact us for custom configurations.

Product Features

  • LED Touch Interface:7-inch color display for multi-parameter real-time visualization.
  • Smart Self-Diagnosis:Automatic sensor fault detection for proactive maintenance.
  • User Calibration Mode:Open-system calibration ensures long-term measurement accuracy.
  • Dynamic Trend Tracking:Real-time curve plotting of temperature, humidity, and dew point.
  • Fast Response Technology:≤10s response time (25°C, 60% RH) for rapid environment adaptation.
  • Dew Point Conversion:Automatic pressure-to-atmosphere dew point adjustment.
  • Data Management System:Large-capacity logging with USB/RS485 (Modbus) export capabilities.

Technical Specifications

Parameter Details
Measured Parameters Temperature, relative humidity, dew point
Dew Point Range -80°C to +20°C (customizable options available)
Temperature Accuracy ±0.5°C (20–50°C operating range)
Humidity Accuracy ±2% RH (20–90% RH, 25°C)
Dew Point Accuracy ±1°C (-60–20°C); ±2°C (-80–60°C)
Response Time (T90) ≤10s (25°C, 60% RH, still air)
Display 7-inch LED touch screen (800×480 pixels)
Communication USB 2.0, RS485 (Modbus RTU protocol)
Power Options AC 220V±10% (50/60Hz) or DC 24V (optional battery pack)
Operating Temperature -20°C to +50°C (non-condensing)
Storage Temperature -40°C to +70°C (battery removed)
Dimensions 190×144×100 mm (panel-mount design)
Installation Panel-mount / wall-mount with optional brackets
