High-Accuracy Rechargeable SF6 Leak Detector [SMART-200-FR]: Tailored For Middle East GIS Manufacturers

Large Image : High-Accuracy Rechargeable SF6 Leak Detector [SMART-200-FR]: Tailored For Middle East GIS Manufacturers

Product Details:

Place of Origin:	Shanghai
Brand Name:	KSTONE
Certification:	ISO9000
Model Number:	SMART-200-FR

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	$600-$650
Packaging Details:	Carton / Wooden Box
Delivery Time:	1 work days
Payment Terms:	T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Gross Weight:	415g (14.6oz)	Power Supply:	Lithium Battery
Packing:	Aluminum Suitcase	Maximum Sensitivity:	Less Than 4g/yr
Sensitivity Adjustment:	Supports Three Levels Of Adjustment (L-Low, M-Medium, H-High)	Working Time:	Continuous Operation For 6 Hours
Highlight:	High-Accuracy SF6 Leak Detector , SMART-200-FR SF6 Leak Detector

Product Overview

The SMART-200-FR Rechargeable Handheld SF6 Gas Leak Detector, based on infrared principle, is a top choice for Middle East GIS manufacturers, power companies, and industries relying on SF6 Vacuum Pump systems. It outperforms traditional detectors, integrating high accuracy, long sensor life, and user-friendliness—critical for maintaining SF6 Vacuum Pump efficiency and safety.

Key Features & Advantages

Exceptional Sensitivity: Detects as low as <4g/yr, with L-M-H 3-level adjustment, ensuring precise leaks detection for SF6 Vacuum Pump-related equipment.
User-Centric Design: Large TFT LCD for intuitive leakage display; UVLED with instant 100% power output (no warm-up); 10-minute auto-shutdown and hardware circuit shut-off to extend battery life.
Reliable Functionality: Power-on self-test, leakage peak recording, sensor fault alarm; buzzer on/off option and earphone function for noisy sites—perfect for GIS factories and power plants using SF6 Vacuum Pump.
Eco-Friendly & Durable: Built-in 3.7V 3000mAh rechargeable lithium battery (longer life, eco-friendly); flexible probe for narrow spaces, adapting to SF6 Vacuum Pump installation and maintenance scenarios.

Technical Parameters

Technical Parameter	Details
Battery	Built-in rechargeable lithium battery, 3.7V, 3000mAh
Working Time	Continuous operation for 6 hours
Charging Time	4 hours
Operating Environment	Temperature: -10°C to 52°C; Relative Humidity: 50% ~ 85% RH
Weight	415g (14.6oz)
Dimensions	201mm × 86mm × 38mm (7.9" × 3.3" × 1.5")

This detector seamlessly complements SF6 Vacuum Pump systems, meeting the strict demands of Middle East GIS manufacturers and power companies for reliable, efficient SF6 leak monitoring.

High-Accuracy Rechargeable SF6 Leak Detector [SMART-200-FR]: Tailored For Middle East GIS Manufacturers 0

High-Accuracy Rechargeable SF6 Leak Detector [SMART-200-FR]: Tailored For Middle East GIS Manufacturers 1
