Custom 380V SF6 Gas Purification Device Recovery System 99.99% Distillation

Large Image : Custom 380V SF6 Gas Purification Device Recovery System 99.99% Distillation

Product Details:

Place of Origin:	Shanghai
Brand Name:	KSTONE
Certification:	ISO9000
Model Number:	KSLF-30WY20/63/100/NZ

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$2000-$100000
Packaging Details:	Carton / Wooden Box
Delivery Time:	60 days
Payment Terms:	T/T
Supply Ability:	10 per year

Contact Now

Detailed Product Description

Vacuum Pump:	Roots Pump	Power Supply:	AC 380V, 50Hz
Vacuum Degree:	≤ 5Pa	Operating Environment:	Temperature: -20℃~+40℃, Humidity: ≤ 90%
Model:	RF-300	Dimensions:	L 4000mm * W 2000mm * H 2000mm
Sf6 Gas Storage Tank Capacity:	1000L	Application:	Recovery And Purification Of SF6 Gas From Electrical Equipment
Weight:	3000kg	Sf6 Gas Purity:	≥ 99.9%
Sf6 Gas Moisture Content:	≤ 100ppm	Capacity:	300m3/h
Sf6 Gas Recovery Rate:	99.6%	Sf6 Gas Pressure:	≤ 0.4Mpa
Highlight:	SF6 Gas Purification Device , 380V SF6 Gas Purification , 380V sf6 recovery system

SF6 Recovery Separation Purification Device – 99.99% Distillation, Filtration, Air-Cooled, KSLF-30WY20/63/100/N

System Overview

This three-in-one device integrates recovery, separation, and purification functions to process SF6 gas contaminated with air, moisture, or decomposition products. Through liquid-solid phase processing, it efficiently discharges N₂, O₂, and other impurities via distillation purification, achieving 99.99% SF6 concentration post-treatment.

Technical Features

Integrated Filtration System: Adsorbs moisture, particles, decomposition byproducts, and oil residues
Compact All-in-One Design: Portable structure for easy on-site deployment
Maintenance-Free Filtration: Self-cleaning mechanism ensures consistent gas quality
Phase Sequence Protection: Prevents motor reversal via built-in protective circuitry
Air-Cooled Operation: Eliminates need for external water supply (ideal for field use)
Extreme Temperature Performance: -20°C to +60°C operational range with thermal protection
Regenerative Desiccant System: Heated activation eliminates replacement needs
Auto-Compensating Valves: Ball valves with self-sealing performance for zero leakage
Vacuum Power Protection: Prevents oil backflow during power outages

Technical Specifications Table

Component	Specification
Model Code	KSLF-30WY20/63/100/N
Purification Efficiency	99.99% SF6 concentration
Processing Capacity	30-100 m³/h (model-dependent)
Filtration Precision	0.1μm particles, ≤3ppm moisture
Cooling System	Air-cooled (no external water required)
Temperature Range	-20°C to +60°C (with thermal protection)
Power Supply	3Φ 380V 50Hz, 7.5-15kW (model-dependent)
Vacuum Level	≤10Pa (ultimate vacuum)
Desiccant Type	Molecular sieve (regenerative via heating)

Functional Flow Diagram

Recovery Stage: Compressed SF6 gas intake via oil-free pump
Separation Stage: Distillation removes N₂/O₂ through temperature gradient control
Purification Stage:
- Particulate filtration (0.1μm)
- Moisture adsorption (molecular sieve)
- Decomposition product removal (chemical adsorption)
