ODM Refrigeration Industrial Air Dryer Machine For Filtering Moisture And Particles

Large Image : ODM Refrigeration Industrial Air Dryer Machine For Filtering Moisture And Particles

Product Details:

Place of Origin:	Shanghai
Brand Name:	KSTONE
Certification:	ISO9000
Model Number:	KS3000-80-cz4

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$2000-$100000
Packaging Details:	Carton / Wooden Box
Delivery Time:	45 days
Payment Terms:	T/T
Supply Ability:	100

Contact Now

Detailed Product Description

Type:	Dehumidifier	Power Supply:	220V/50Hz
Auto Shut-Off:	Yes	Power Consumption:	750W
Operating Temperature:	5-35°C	Water Tank Capacity:	5 Liters
Dehumidifying Method:	Refrigeration	Air Flow Rate:	300m³/h
Humidity Control:	Digital Control	Noise Level:	≤50dB
Timer Function:	Yes	Capacity:	50 Liters Per Day
Highlight:	Refrigeration industrial air dryer , ODM industrial air dryer , ODM air dryer machine

Dry Air Manufacturing Equipment, Filtration Method, 30ppm, Filter And Dry Natural Air Equipment KS3000-80-cz4

Ks3000-80-cz4, By filtering moisture and particles from natural air, dry air with a moisture content of less than 30ppm (v) can be produced.
The flow rate of dry air can be selected as needed.
This device can be used to provide air source for air insulated cabinets.
The device can also provide dry air to flush the gas insulated cabinet instead of high-purity nitrogen.
The device also has a vacuum pumping function and can expand the vacuum pump as needed.
The equipment includes a silent compressor, moisture filtration device, drying activation device, pressure adjustable system, and exhaust pipe. The equipment also includes a vacuum pump, anti reflux device, and pipelines. The device can also be equipped with an online micro water testing sensor (optional, model: KS3000-80-CZ4-WS), mainly used to determine whether the device needs to be activated.
Can be configured as fully automatic or manual according to requirements;
Main parameters:
Compressor: flow rate of 80L/min (optional).
Pressure adjustable system: can provide any adjustable value within the range of 0.1-6.0 Mpa, and can set low pressure and fluctuation range.
For example, for a certain customer, the low pressure is 0.12 Mpa and the fluctuation range is 0.02 Mpa. When the output air pressure is greater than 0.14Mpa, the compressor stops running, and when the pressure is lower than 0.12Mpa, the compressor starts.
Drying and activation device: If the micro water value of the outlet gas exceeds the required value, remove the gas outlet pipeline, open the gas outlet valve, start the drying and activation device, and set the time to 30 minutes. After 30 minutes, the adsorbent returns to its initial state. According to testing, one regeneration can provide approximately 15m ³ of qualified dry air.
Moisture filtration device: After multiple improvements to the solution, the trace water in the outlet gas can be effectively controlled at 30-50ppmv under the condition of 70% humidity in the inlet environment.
Vacuum pump: 15m ³/h.

Item	Technical Specification
Dimensions (Length×Width×Height, LBH)	1200×800×1620
Weight (Kilogram, Kg)	≤150
Power Supply	AC220
Power (Kilowatt, Kw)	≤6
Moisture Absorption Amount per Activation (Kilogram, Kg) (<50 - 60ppm)	≥1.0
