OEM Touchscreen SF6 Monitor Sensors Gas Density Meter Device

Large Image : OEM Touchscreen SF6 Monitor Sensors Gas Density Meter Device

Product Details:

Place of Origin:	Shanghai
Brand Name:	KSTONE
Certification:	ISO9000
Model Number:	KS-201

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	$2000-$100000
Packaging Details:	Carton / Wooden Box
Delivery Time:	7-10 work days
Payment Terms:	T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Features:	High Measurement Accuracy	Wide Temperature Work:	-40～+80°C
Data Analysis:	Real-time	Compatibility:	Multi-device
Gprs Mode:	Support	System Highlights:	Sound And Light Caveat
Average Power Consumption:	<2W	Design Highlights:	Low Power Design
Highlight:	Touchscreen sf6 monitor , OEM sf6 monitor , OEM sf6 gas density meter

KS-201 Online Dew Point & Temperature Humidity Meter | Imported Sensors, Touch Screen Calibration

Brief Introduction

The KS-201 online dew point and humidity meter utilizes high-precision imported sensors to deliver accurate, stable measurements. Its integrated system enables real-time monitoring, data management, time scheduling, and parameter configuration, featuring a touch-screen interface for intuitive operation. Ideal for new energy, petrochemicals, semiconductors, power grids, and pharmaceutical industries, it suits online gas environment analysis with strict control requirements. The device supports standalone use or multi-sensor setups with a central host—contact us for custom configurations.

Product Features

LED Touch Interface:7-inch color display for multi-parameter real-time visualization.
Smart Self-Diagnosis:Automatic sensor fault detection for proactive maintenance.
User Calibration Mode:Open-system calibration ensures long-term measurement accuracy.
Dynamic Trend Tracking:Real-time curve plotting of temperature, humidity, and dew point.
Fast Response Technology:≤10s response time (25°C, 60% RH) for rapid environment adaptation.
Dew Point Conversion:Automatic pressure-to-atmosphere dew point adjustment.
Data Management System:Large-capacity logging with USB/RS485 (Modbus) export capabilities.

Technical Specifications

Parameter	Details
Measured Parameters	Temperature, relative humidity, dew point
Dew Point Range	-80°C to +20°C (customizable options available)
Temperature Accuracy	±0.5°C (20–50°C operating range)
Humidity Accuracy	±2% RH (20–90% RH, 25°C)
Dew Point Accuracy	±1°C (-60–20°C); ±2°C (-80–60°C)
Response Time (T90)	≤10s (25°C, 60% RH, still air)
Display	7-inch LED touch screen (800×480 pixels)
Communication	USB 2.0, RS485 (Modbus RTU protocol)
Power Options	AC 220V±10% (50/60Hz) or DC 24V (optional battery pack)
Operating Temperature	-20°C to +50°C (non-condensing)
Storage Temperature	-40°C to +70°C (battery removed)
Dimensions	190×144×100 mm (panel-mount design)
Installation	Panel-mount / wall-mount with optional brackets
