Full Auto SF6 Vacuum Pump Unit Air Cooled Leybold Raffles Dilo Gas Cart

Large Image : Full Auto SF6 Vacuum Pump Unit Air Cooled Leybold Raffles Dilo Gas Cart

Product Details:

Place of Origin:	Shanghai
Brand Name:	KSTONE
Certification:	ISO9000
Model Number:	KSCZ-300/1000Z

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$2000-$100000
Packaging Details:	Carton / Wooden Box
Delivery Time:	45 days
Payment Terms:	T/T
Supply Ability:	10 per year

Contact Now

Detailed Product Description

Features:	High Vacuum Degree, High Flow Rate, Compact Design	Frequency:	50Hz
Power Source:	Electric	Power:	15kW
Usage:	Industrial	Type:	Vacuum Pump
Max Vacuum:	1pa	Max Flow Rate:	1000m3/h
Application:	Vacuum Pumping And Inflation	Inlet/Outlet Diameter:	DN20
Voltage:	380V
Highlight:	Raffles SF6 Vacuum Pump , Leybold SF6 Vacuum Pump , Leybold dilo gas cart

Full-Auto Vacuum Pumping Unit – Air-Cooled, Hand-Push Mobile, Leybold or Made in China (optional) Pumps KSCZ-300/1000Z

Technical Parameters and Performance Indicators of the Device

Model		KSCZ-300/1000Z
Type		Air-cooled hand-push mobile type
Operating Environment Temperature		-10℃～40℃
Pre-stage Vacuum Pump	Extraction Rate (m³/s)	300
	Ultimate Vacuum (Pa)	≤20
	Power (kW)	7.5
	Brand	Leybold
Roots Vacuum Pump	Extraction Rate (m³/s)	1000
	Ultimate Vacuum (Pa)	≤10
	Power (kW)	4
	Brand	Leybold
External Interface		Dn20 4 channels (default)
Power Supply		Three-phase four-wire system 3Φ 380V
Total Power (kW)		≤15
Noise dB(A)		≤75

The electrical system automatically verifies and manually adjusts the three-phase power supply.

It is also equipped with a phase loss protection function, which can effectively prevent the reverse rotation of the vacuum pump and the operation of all main units under phase loss conditions. Additionally,

it has a power failure protection function to prevent oil backflow in the vacuum pump during power outages.
